Furnace Structure

• Energy-saving high-purity Al2O3 fibrous insulation liner
• Steel shell with adjustable height
• Adjust three knobs on the back to flexibly change the furnace's vertical position within travel distance (from the control box platform to the lower end of the chamber): 4.5'' ~ 12'' (without hanger and supporter)
• Multiple configurations for various processing applications
• Fixing Knobs for Position Adjustment Multi-position adjustable

Power

• AC 110V Single Phase or AC 220V Single Phase can be selected in the option bar
• 1500W ( 15A air breaker required )

Working Temperature

• Max. Temperature: 1100 °C (< 1 hr)
• Continuous working temperature: 1000 °C
• Max. Heating Rate: 10°C /min

• Heating Zone Length: 12" (300mm)
• Constant Temperature Zone: 3.1" (80mm)
• Heating element: Fe-Cr-Al Alloy doped by Mo

Temperature Controller

• PID automatic control and auto-tune function.
• 30 programmable segments for the precise process
• Built-in protection for overheated and broken Thermal couple.
• Temperature Accuracy: +/- 1 °C
• K-type thermal couple

Advanced Temperature Controller (Optional)

• Temperature control software kit (for YUDIAN series controllers) + 15" laptop package is available at the options bar. Click for detailed information about the MTS02-Y software kit.

Dimensions

Shipping Package Dimensions

40"(L) x 30"(W) x 30"(H)

Shipping Weight

80 lbs

Warranty

• CE Certified
• NRTL or CSA certification (UL61010 or SPE1000) is available at the extra cost.
