15 mm Dia LiFePO4 (LFP) Single Side Coated Cathode Electrode Disk for CR20XX Coin Cells 100 pcs/ pack - bcaf-LFP15

Product image 1
1 / 4

15 mm Dia LiFePO4 (LFP) Single Side Coated Cathode Electrode Disk for CR20XX Coin Cells 100 pcs/ pack - bcaf-LFP15

bcaf-LFP-15 is a pre-cut LiFePO4 coated cathode electrode for CR20XX coin cell battery R&D and split testing.

SPECIFICATIONS:
Material
  • LiFePO4 Coated on Aluminum Foil
Diameter
  • 15 mm
Coating Thickness
  • 32 um (total thickness with Al foil is ~48 um)
Coating
  • Single side coating
Aluminum foil
  • Thickness 16 um
Coating Area Density
  • 13.5 ± 0.20 mg/cm2
Compaction Density
  • 2.0 ± 0.1g/cm3
Active materials Mass Proportion
  • 95.4% (PVDF and Super P is 2% and 2.6%, respectively)
Capacity
  • 150 mAh/g (Area Capacity: 2.025 mAh/cm2); 0.1 C; 2.5-3.7 V; Electrolyte: 1.0M LiPF6 in EC:DMC: EMC=1:1:1 Vol% with 1.0%VC
Operation
  • The package must be opened inside a glove box with Argon Gas and moisture less than 2%RH.
  •
Note
  • This product is not manufactured by MTI. We only sell small quantities to research for developing new materials. If you have any questions on IP conflict, we will forward your inquiry to the manufacturer.



$86.80

Original: $248.00

-65%
15 mm Dia LiFePO4 (LFP) Single Side Coated Cathode Electrode Disk for CR20XX Coin Cells 100 pcs/ pack - bcaf-LFP15—

$248.00

$86.80

Product Information

Shipping & Returns

Description

bcaf-LFP-15 is a pre-cut LiFePO4 coated cathode electrode for CR20XX coin cell battery R&D and split testing.

SPECIFICATIONS:
Material
  • LiFePO4 Coated on Aluminum Foil
Diameter
  • 15 mm
Coating Thickness
  • 32 um (total thickness with Al foil is ~48 um)
Coating
  • Single side coating
Aluminum foil
  • Thickness 16 um
Coating Area Density
  • 13.5 ± 0.20 mg/cm2
Compaction Density
  • 2.0 ± 0.1g/cm3
Active materials Mass Proportion
  • 95.4% (PVDF and Super P is 2% and 2.6%, respectively)
Capacity
  • 150 mAh/g (Area Capacity: 2.025 mAh/cm2); 0.1 C; 2.5-3.7 V; Electrolyte: 1.0M LiPF6 in EC:DMC: EMC=1:1:1 Vol% with 1.0%VC
Operation
  • The package must be opened inside a glove box with Argon Gas and moisture less than 2%RH.
  •
Note
  • This product is not manufactured by MTI. We only sell small quantities to research for developing new materials. If you have any questions on IP conflict, we will forward your inquiry to the manufacturer.
