Single Channel Laser Etching Machine for Scribing (P1, P2, P3, P4) of Perovskite Solar Cells (100mm*100mm), MSK-PSP-LSS1010

Product image 1
1 / 2

Single Channel Laser Etching Machine for Scribing (P1, P2, P3, P4) of Perovskite Solar Cells (100mm*100mm), MSK-PSP-LSS1010

The MSK-PSP-LSS1010 is a small, single channel laser etching machine with features of high flexibility, accuracy, and speed, which can be used for laser scribing (P1, P2, P3, P4) of perovskite solar cells.

SPECIFICATIONS:

Advanced Features
  • Solid-state laser with wavelength of 532 nm, which is used for precising etching of conductive glasses and thin films.
  • Professional controlling software that is compatible with CAD file for convenient laser scribing
  • Software is capable of regulating the vibration mirror, motor, and lifting platform to ensure stable operation
  • Unique dedusting system design to ensure cleanness of substrate and platform.
Input Voltage
  • AC 220V +/- 10%, 50/60 Hz, single phase, 1 kw
Laser Wavelength
  • 532 nm
Laser Power
  • 5 W, nanosecond laser
  • (other powers are available upon request, such as 15 W, picosecond laser, working area: 300mm*300mm)
Working Area
  • 100 mm * 100 mm
Laser Focus Spot
  • < 50 um
CCD Positioning Accuracy
  • ±10μm
XY Motor Accuracy
  • ±10μm
Laser Frequency Range
  • 1-150 kHz
Min. Etching Line Width
  • < 50 um (95% oxide coating can be removed)
Min. Line Distance
  • < 50 um
Etching Speed
  • < 4000 mm/s
Processing Substrates
  • ITO/FTO/flexible PET/other thin films
Laser Scribing Effect
  • Some typical laser scribing effects are shown below:





Dimension
  • L735mm * W1050mm * H1850mm
Weight
  • ~350 kg







$20,993.00

Original: $59,980.00

-65%
Single Channel Laser Etching Machine for Scribing (P1, P2, P3, P4) of Perovskite Solar Cells (100mm*100mm), MSK-PSP-LSS1010—

$59,980.00

$20,993.00

Product Information

Shipping & Returns

Description

The MSK-PSP-LSS1010 is a small, single channel laser etching machine with features of high flexibility, accuracy, and speed, which can be used for laser scribing (P1, P2, P3, P4) of perovskite solar cells.

SPECIFICATIONS:

Advanced Features
  • Solid-state laser with wavelength of 532 nm, which is used for precising etching of conductive glasses and thin films.
  • Professional controlling software that is compatible with CAD file for convenient laser scribing
  • Software is capable of regulating the vibration mirror, motor, and lifting platform to ensure stable operation
  • Unique dedusting system design to ensure cleanness of substrate and platform.
Input Voltage
  • AC 220V +/- 10%, 50/60 Hz, single phase, 1 kw
Laser Wavelength
  • 532 nm
Laser Power
  • 5 W, nanosecond laser
  • (other powers are available upon request, such as 15 W, picosecond laser, working area: 300mm*300mm)
Working Area
  • 100 mm * 100 mm
Laser Focus Spot
  • < 50 um
CCD Positioning Accuracy
  • ±10μm
XY Motor Accuracy
  • ±10μm
Laser Frequency Range
  • 1-150 kHz
Min. Etching Line Width
  • < 50 um (95% oxide coating can be removed)
Min. Line Distance
  • < 50 um
Etching Speed
  • < 4000 mm/s
Processing Substrates
  • ITO/FTO/flexible PET/other thin films
Laser Scribing Effect
  • Some typical laser scribing effects are shown below:





Dimension
  • L735mm * W1050mm * H1850mm
Weight
  • ~350 kg
